Copper Mobile Crusher

Natural Copper Storage Form: Bornite, Cuprite, Chalcopyrite, Malachite, Tennantite, Tetrahedrite, Chalcocite.
Copper Description: Copper Ore Mobile Crusher can be divided into two types according to its' drive mode: tyre type portable mobile plants and crawl type combined track mobile machines.
Mobile copper crushers can also be divided according to its' function main unit: mobile jaw crusher, mobile cone crusher and mobile impact crusher. The belt conveyor and screen are already included in the whole mobile station to improve the flexibility.

Copper Mineral Dressing Mobile Crusher Manufacturer

Seen from the high degree feedback from our customers around the world, mobile series copper crushing machines applicated in copper mining industry gained great success. SBM mining machinery company committed to the exploitation of this advanced equipment to more mineral quarry crushing line, gratifying to achieve a win-win situation. As one of China's first mobile mining industry device manufacturers, we have rich experience in manufacturing, maintenance and installation, thus we are more than equal to provide advice and technical support for your investment.

Copper Mining - Application Area

Coppercan be used as appliances, instruments, piping, electrical applications, architecture and industry, household products, coinage, biomedical applications, chemical applications, miscellanea etc. This series of mobile crusher is widely used in copper, iron ore, zinc, gold and other metal or no-metal mineral dressing industry. It can reach the crushing ratio of 4-6 and the shape of final product is even. They are widely applied to crush high hardness, mid hardness and soft rocks and ores such as slags, construction materials, marble, etc. The pressure resistance strength is under 200Mpa, suitable for primary crush. Copper mobile crusher can be used in mining, metallurgical industry, construction, road and railway building, conversancy, chemistry, etc.

Copper Ore Mobile Jaw Crusher ( tyre ) Specification

Model Parameters	Weight (T)	Tire configuration and installation	Crusher Type	Max feed (mm)	Discharge port adjustment range (mm)	Capacity (t/h)	Feeder Type	Main belt conveyer model	Side belt conveyer model (optional)	Generator Power (optional)	Magnetic separator
YG938E69	39	dual-axis C	PE600 ×900	480	65~160	90~180	GZD960 ×3800	B800×8.5M	B450×3M	180	RCYD(C)-8
YG1142E710	57	three-axis C	PE750 ×1060	630	80~140	110~320	GZD1100 ×4200	B1000×9M	B500×3.5M	220	RCYD(C)-10
YG134E912	83	three-axis C	PE900 ×1200	750	95~165	220~450	GZD1300 ×4900	B1200×9.5M	B650×4M	250	RCYD(C)-12
YG134J811	65	three-axis C	PEW840 ×1100	720	100~225	200~500	GZD1300 ×4900	B1200×9.5M	B650×4M	270	RCYD(C)-12

Note: This specification is just reference, any changes are subject to the products

Copper Ore Mobile Cone Crusher ( tyre ) Specification

Parameter Model	Vibrating screen	Cone crusher	Belt conveyor (down)	Capacity (t/h)	Power (kw)
Y3S1548Y55	3YA1548	PYB900	B500X7M	50-90	75
Y3S1848Y90	3YA1848	HCS-90	B650X7M	65-130	99-134
Y3S1860Y160	3YA1860	CS-160	B650X8M	110-455	212.5-220.5
Y3S2160Y220	3YA2160	HPC-220	B800X8M	140-330	257.5-264.5

Note: This specification is just reference, any changes are subject to the products

Copper Ore Mobile Impact Crusher ( tyre ) Specification

Parameter Medol	Vibrating screen	Impact crusher	Belt conveyor (down)	Capacity (t/h)	Power (kw)	Length L1	Width B1	height H1	Max. height H2	Max. width B2	Heigth of belt conveyor H3	wheel	Weight (t)
Y3S1548 F1010	3YA 1548	PF 1010	B500 X7M	30-275	70-90	12500 mm	2500 mm	4000 mm	6000 mm	2800 mm	4000 mm	Paratactic double axles	42
Y3S1848 F1210	3YA 1848	PF 1210	B650 X7M	56-330	128.5-150.5	12500 mm	2800 mm	4500 mm	6500 mm	3000 mm	4000 mm	Paratactic double axles	46
Y3S1860 F1214	3YA 1860	PF 1214	B650 X8M	65-586	154-190	13500 mm	2800 mm	4500 mm	6500 mm	3000 mm	4200 mm	Paratactic tri- axle	51
Y3S2160 F1315	3YA 2160	PF 1315	B800 X8M	81-720	210-297	14000 mm	3000 mm	4800 mm	6500 mm	3200 mm	4200 mm	Paratactic tri- axle	57

Note: This specification is just reference, any changes are subject to the products

Copper Ore Combined Track Crusher ( crawler ) Specification

Parameter Medol	Track broad width (mm)	Track length (mm)	Track gauge (mm)	Track width (mm)	Operating length (mm)	Operating width (mm)	Operating height (mm)	Minimum ground clearance (mm)	Pressure Flow Min	Max. speed (km/h)	Climbing grade (%)	Engine power (kw)	Engine speed (kw)
Y2S1848L	2990	4250	2390	600	15800	3150	4500	320	28Mpa/180L	1.39	30	92	2100
YGE69L	2990	4250	2390	600	15200	3150	4900	320	28Mpa/180L	1.39	30	150	2100
Y2S184F00	2990	4250	2390	600	13800	2900	4100	320	28Mpa/180L	1.39	30	150	2100

Note: This specification is just reference, any changes are subject to the products
