Copper Belt Conveyor

We offer large selection of belted conveyors in the industry with over 30 pre-engineered models for every application that are built to the customer’s specifications. This ensures each customers finds the perfect configuration for their product. With patented rack and pinion technology for belt tensioning and an engineered v-guide process technology to ensure belt tracking, SBM belt conveyors are the most efficient, precise conveyor systems on the market. All conveyors are run before being shipped to ensure out-of the-box optimum performance, saving the customer time and giving peace of mind. Once inspected and tested, most conveyors ship in 3 days.

Working Principle Description-Copper Mineral Belt Conveyor

Belt conveyors are the backbone of any mining or quarrying operation. Systems that ensure the bulk movement of material in excess of 1000 Tonnes per hour are commonplace within the industry, with the carrying length of the conveyor system virtually unlimited, the system can convey material from the quarry to the processing plant without the need for heavy transport. Combinations of conveyors Weighers, Crushers, Magnets and Screens ensure the end product is sized and free from tramp metal ready or the next process. The belt conveyor has the flexibility of design to accommodate inclines and declines, enabling the structure to follow hillsides or to bridge over obstacles.

Application Area

Looking for a specific belt conveyor product solution? Check out our Heavy Duty Belt Conveyors for high speed and bulky industrial applications, which take space saving into design, or get introduction right now with our online service. This series of Belt Conveyor is widely used in copper, iron ore, zinc, gold and other metal or no-metal mineral dressing industry. It can reach the crushing ratio of 4-6 and the shape of final product is even. They are widely applied to crush high hardness, mid hardness and soft rocks and ores such as slags, construction materials, marble, etc. The pressure resistance strength is under 200Mpa, suitable for primary crush. Copper Belt Conveyor can be used in mining, metallurgical industry, construction, road and railway building, conversancy, chemistry, etc. Some commen process meterials : * Black trap, Basalt; * Granite, River gravel; * Bauxite, Hard Rock; * Lime Stone,Coal; * Iron ore, Maganize ore.

Copper Belt Conveyor Specification

Belt Width (mm)	Belt Length (m) /Power (Kw)			Belt Speed (m/S)	Capacity (t/h)
400	≤12/1.5	12~20/2.2	20~25/3	0.8~2.0	40~80
500	≤12/3	12~30/4	20~30/5.5	0.8~2.0	78~191
650	≤12/4	12~20/5.5	20~30/7.5	0.8~2.0	131~323
800	≤10/4	10~15/5.5	15~25/7.5	1.0~2.0	278~546
1000	≤10/5.5	10~20/7.5	20~25/11	1.0~2.0	435~853
1200	≤10/7.5	10~20/11	20~25/15	1.0~2.0	655~1284

Note: This specification is just reference, any changes are subject to the products

SBM has designed, built and installed robust, reliable bulk material handling conveyor equipment into quarry operations around the globe. Bespoke designed conveyor systems suited to the material environment and climate of the operation. Multiple installations into quarrying industries such as: Oil, Cement, Chalk, Flint Potash, Gold, Coal, Gypsum, Iron Ore and Aggregates. Combining traditional heavy engineering with modern computer aided design packages, the SBM engineers design and build the conveyor systems for the robust operation needed and expected by the customer.
