Copper Ore Grinding Mill

Copper Ore Grinding Mill began as a pioneer brand of Shibang Machinery Company in the field of Crushing Equipments. The quality copper Grinding Mill include Raymond Mill, Vertical Roller Grinding Copper Mill, Copper Ore Ball Mill, Superfine Micro Powder Grinding Mill and MTW Grinding Mill. A grinding mill is a unit operation designed to break a solid material into smaller pieces. Mineral Grinding Mill can produce powder from various non-flammable and non-explosive mineral materials whose Mohs hardness is below 9.3 and humidity below 6%, such as barite, limestone, kaolin, ceramics and slag, etc. The Product size is adjustable in the range of 80-425 mesh. It is possible to produce 30-80 mesh coarse powder through special device in the machine if necessary.

Working Principle Description
- Copper Mineral Dressing Grinding Mill

ThisIn the mainframe of the Copper Grinding Mill (suspension mill), there are strong springs with pressure as high as1000-1500 kg equipped on the roller suspender. When the Copper Grinding Mill (suspension mill) works, the roller rotates around the principal axis, and clings to ring under the effect of the strong spring and eccentricity. When the materials are sent into the grinding chamber of the Copper Grinding Mill (suspension mill), they are brought to the space between the roller and ring and get grinded. Then the powder grinded by the Copper Grinding Mill (suspension mill) will be blown into separator. The fine powder after departed with the air is discharged through the outlet as final product. The large-sized powder falls back for regrinding. The air will be back to the blower for repetition of the above process. The left air will come to the bag filter to get cleaned. When the wear and tear between roller and the ring reaches certain degree, adjust the length of the strong spring, so to keep the invariable pressure between the roller and the ring, to make sure the stable production and the fineness when the Copper Grinding Mill (suspension mill)works.

Application Area

This series of Grinding Mill is widely used in copper, iron ore, zinc, gold and other metal or no-metal mineral dressing industry. It can reach the crushing ratio of 4-6 and the shape of final product is even. They are widely applied to crush high hardness, mid hardness and soft rocks and ores such as slags, construction materials, marble, etc. The pressure resistance strength is under 200Mpa, suitable for primary crush. Copper Grinding Mill can be used in mining, metallurgical industry, construction, road and railway building, conversancy, chemistry, etc. Some commen process meterials : * Black trap, Basalt; * Granite, River gravel; * Bauxite, Hard Rock; * Lime Stone,Coal; * Iron ore, Maganize ore.

Copper Grinding Mill Company

A modern copper grinding mill must be able to deal with many tasks while providing a high-degree of grindability, with results that are fine and exact. Only a ball mill of the highest standards, backed by a strong company with a long history in the field will do; only a mill from Retsch meets this challenge. Although we have been producing the highest-quality laboratory equipment for 20 years, we do not rest on the reputation of past products. Shanghai Shibang Mining and Construction Machinery Co., Ltd. is a high technology, engineering group. We are specializing in the research, development, and production of industrial copper grinding mill equipment and pertinent devices. Our products have been sold to 56 countries and areas of Southeast Asia, East Europe, South America, the Middle East and Africa etc, and more foreign markets will be promoted in future.

Copper Powder Ball Mills Specification:

Model	Speed of bucket (r/min)	Weight of ball	Size of feed opening (mm)	size of outputting feed (mm)	Production (t/h)	Power (kw)	Weight (T)
Ф 1830 × 3000	24	11	≤25	0.074~0.4	4-10	180	28
Ф 1830 × 6400	24	23	≤25	0.074~0.4	6.5-15	210	34
Ф 1830 × 7000	24	25	≤25	0.074~0.4	7.5-17	245	36
Ф 2200 × 5500	21	30	≤25	0.074~0.4	10-22	370	48.5
Ф 2200 × 6500	21	30	≤25	0.074~0.4	14-26	380	52.8
Ф 2200 × 7500	21	33	≤25	0.074~0.4	16-29	475	56

Copper Mineral Grinding Raymond Mill Specification:

Type	Roller			Ring		Max. Feeding size (mm)	Fineness of product (mm)	power for Machine (kw)
	NO	dimension (mm)	height (mm)	Inner Diameter (mm)	height (mm)
3R 2115	3	210	150	630	150	15	0.44-0.165	15
3R 2615	3	260	150	780	150	15-20	0.44-0.165	18.5
3R 2715	3	270	140	830	140	15-20	0.44-0.165	22
3R 3016	3	300	160	880	160	15-20	0.44-0.165	30
4R 3216	4	320	160	970	160	20-25	0.44-0.165	37

Copper Ore Vertical Roller Mill Specification:

Model		LM130K	LM150K	LM170K	LM190K	LM220K	LM240K
Turnplate diameter (mm)		1300	1500	1700	1900	2200	2400
Capacity (t/h)		10~30	13~40	18~57	23~72	36~114	41~128
Final product size	μm	170~45	170~45	170~45	170~45	170~45	170~45
	mesh	80~325	80~325	80~325	80~325	80~325	80~325
Final product water percentage		≤1%	≤1%	≤1%	≤1%	≤1%	≤1%
Max. input size (mm)		<38	<40	<42	<45	<50	<55
Best water percentage of raw material		<4%	<4%	<4%	<4%	<4%	<4%
Drying needed if water percentage is more than		<15%	<15%	<15%	<15%	<15%	<15%
Input wind temperature (℃)		<350	<350	<350	<350	<350	<350
Output wind temperature (℃)		70~95	70~95	70~95	70~95	70~95	70~95
Main motor power (KW)		185~220	250~280	355~400	450~500	710~800	800~900
Overall dimensionL×W×H(mm)		3500×3400×5800	4200×3900×7100	4700×4500×8300	8500×5600×8800	10200×6700×10600	11700×7700×12200
Weight (t)		48	75	90	100	125	160

Micro Copper Powder Super Fine Mill Specification:

Model	Roller number	Diameter (mm)	Ring number	Main unit speed (mm)	Max. feeding size (mm)	Final size (mesh)	Capacity (kg/h)	Overall dimension (m)
SCM6015	15	Φ600	1×3	235	10	325-2500	325-2500	10×2.3×5.5
SCM8021	21	Φ800	1×3	235	10	325-2500	600-4000	13×3×5.8
SCM10027	27	Φ1000	1×3	173	10	325-2500	900-6800	18×4×8.6
